ACREL Multifunction Power Meter | 3-Phase AC Energy & Power Quality Monitorin

The Multifunction Power Meter | 3-Phase AC Energy & Power Quality Monitoring Meter is an advanced multifunction power meter designed to measure, monitor, and analyze electrical parameters in three-phase AC power systems. It combines comprehensive electrical measurement, energy monitoring, power quality analysis, communication, and data management functions in a single intelligent meter.

It is designed to measure important electrical parameters including voltage, current, active power, reactive power, apparent power, power factor, frequency, and electrical energy. Depending on the specific configuration, it can also provide advanced monitoring functions such as harmonic analysis, voltage and current unbalance monitoring, demand measurement, and power quality analysis.

The meter can be integrated into centralized electrical monitoring and energy management systems. Through available communication interfaces, measurement data can be transmitted to SCADA platforms, energy management systems, building management systems, industrial automation systems, and other supervisory platforms.

How Does It Work?

• The Multifunction Power Meter | 3-Phase AC Energy & Power Quality Monitoring Meter is connected to the monitored three-phase AC electrical system using appropriate voltage and current inputs.
• It continuously measures voltage and current from the monitored electrical circuits.
• The meter processes the measured signals to calculate active, reactive, and apparent power.
• It monitors power factor and frequency to provide information about electrical system operating conditions.
• The meter measures and records active and reactive energy for ongoing energy monitoring and analysis.
• Advanced power quality functions can provide information about harmonic distortion, voltage and current unbalance, and other electrical system conditions.
• The integrated color LCD display provides local access to electrical measurements and meter information.
• Communication interfaces allow measured data to be transmitted to centralized monitoring platforms.
• RS485 Modbus-RTU communication supports integration with compatible industrial monitoring and automation systems.
• Ethernet communication options can provide network connectivity for centralized data collection, depending on the selected configuration.
• Optional expansion modules can extend the meter's functionality with additional communication, input, output, and other monitoring capabilities.
• The Multifunction Power Meter | 3-Phase AC Energy & Power Quality Monitoring Meter can therefore operate as part of a broader power monitoring, energy management, or electrical automation system.

Why Choose this Product?

• Comprehensive electrical measurement – Monitors a broad range of electrical parameters using a single multifunction meter.
• Advanced power quality monitoring – Provides detailed electrical information to help identify harmonic distortion and other power quality concerns.
• High-accuracy measurement – Designed to provide reliable measurement for demanding electrical monitoring applications.
• Real-time electrical visibility – Gives operators immediate information about system performance and operating conditions.
• Flexible communication – Supports integration with centralized monitoring platforms through available communication interfaces.
• Expandable functionality – Optional modules provide flexibility for applications requiring additional I/O or communication functions.
• Color LCD display – Provides a clear and convenient interface for viewing electrical measurements.
• Centralized monitoring capability – Measurement data can be integrated into SCADA, energy management, and building management systems.
• Wide application range – Suitable for industrial facilities, commercial buildings, data centers, power distribution systems, and critical infrastructure.

Benefits

• Provides detailed visibility into three-phase electrical system performance.
• Helps users understand energy consumption and electrical load conditions.
• Supports identification of abnormal electrical conditions.
• Helps detect harmonic distortion and potential power quality problems.
• Supports energy efficiency analysis and electrical system optimization.
• Enables centralized monitoring and remote data collection.
• Reduces the need for multiple individual measuring instruments.
• Provides convenient local access to electrical information through the color LCD display.
• Supports integration with SCADA, EMS, BMS, and industrial automation systems.
• Expandable design allows the meter to adapt to different monitoring requirements.
• Helps improve electrical system reliability and operational awareness.
• Supports preventive maintenance by providing detailed electrical system information.
• Suitable for demanding industrial and commercial power monitoring environments.
